Water Injected – DH Series
Details
Low operating temperatures and maintenance free sealed bearings eliminate the need for lubricating oil in the compressor. In addition to its oil-free distinction, CompAir DH Series is referred to as an oil-less line because it contains no oil in the compression chamber nor anywhere else in the package.
Design
At the heart of the compressor package is a high output single screw compression element which uses water injection technology for lubrication and cooling. Simplified construction and reduced component count decrease the number of moving parts, which drastically improves reliability.
Effectively lubricates, seals and cools the compression process.
CompAir offers several options of Delcos Controllers from a standard built-in touch screen to the industry’s only dual-position controller. Our Delcos Controllers are simple user friendly controls that are easy to understand and use
Specifications
CompAir Model | Rated Pressure psig | Output FAD cfm | Motor Power HP | Net Weight lbs | Dimensions L x W x H inches |
---|---|---|---|---|---|
D15H RS | 75-145 | 11.3-82.64 | 20 | 1515 | 53 x 35 63 |
D22H RS | 75-145 | 24-121.84 | 30 | 1556 | |
D37H RS | 75-145 | 38.5-242.61 | 50 | 2194 | 68 x 36 x 65 |
D50H RS | 75-145 | 43.44-266.27 | 67 | 3461 | 85 x 56 x 78 |
D75H RS | 75-145 | 65.69-400.47 | 100 | 4167 | |
D110H RS* | 75-150 | 111.95-651.91 | 150 | 4850 |
* D110H RS only available water cooled.
Two Stage Dry Screw – D Series
CompAir’s two-stage D Series oil free compressor combines years of engineering expertise to create a product that can be relied upon to deliver a consistent flow of high quality, clean and economical compressed air. These machines are perfect for several industries where air quality is not only important but also vital to product integrity.
Details
CompAir D-Series two stage dry rotary screw compressors provide a reliable supply of oil-free compressed air for a wide variety of high technology industries. These oil-free packages are fully enclosed for quiet operation and increased versatility. Engineered for serviceability and ease of installation, D Series compressors are fully integrated with conveniently grouped service components. Air and water cooled options available
Design
The compression chamber is protected against the ingress of bearing lubricant by guaranteed non-contact non-wearing labyrinth seals. The CompAir compression element design sets the industry standard for energy efficiency. Advanced asymmetrical rotor profiles and optimized radial and axial porting ensure maximum air output for decreased energy consumption.
Features Include:
- Independently driven oil pump
- Machines that are perfect for many industries such as food & beverage, pharmaceutical, electronics and automotive
- Excellent efficiency due to unique design features
- Optimized air cooling system
- Extended compression element life
Controller
SureScan – CompAir’s SureScan microprocessor-based compressor management system simplifies operation and allows instant review of the compressor’s status. Comprehensive control, condition monitoring, protection and remote control facilities are incorporated into this controller. With superior flexibility built in, the SureScan controller can meet specific control requirements such as:
- Remote start and stop
- Remote load and unload
- Automatic power failure restart
- Available output
- Running output
- Onload output
- Service due output
- Group alarm and trip outputs
- RS485 communications interface for remote monitoring and control
Specifications
CompAir Model | Rated Pressure psig | Output FAD cfm | Motor Power HP | Net Weight lbs | Dimensions L x W x H inches |
|
---|---|---|---|---|---|---|
D55-08A | 125 | 266 | 75 | 5,038 | 114 x 63 x 81 | |
D75-08A | 125 | 401 | 100 | 5,478 | ||
D75-10A | 145 | 349 | ||||
D90-08A | 125 | 520 | 125 | 5,632 | ||
D90-10A | 145 | 462 | ||||
D110-08A | 125 | 630 | 150 | 6,138 | ||
D150-08A | 125 | 796 | 200 | 6,486 | ||
D150-10A | 145 | 768 | ||||
D75-10W | 152 | 330 | 100 | 5,120 TEFC | 114 x 63 x 81 | |
D90-10W | 152 | 462 | 125 | 5,341 TEFC | ||
D90-07W | 110 | 491 | ||||
D110-07W | 110 | 700 | 150 | 5,341 TEFC | ||
D150-10W | 152 | 696 | 200 | 6,267 TEFC |
