Features
Features
- Dual oil splash lubrication at both gear and drive ends available on some models
- Triple lip seals standard on all models
- Sight glasses standard on all models
- Magnetic drain plugs standard on all models
- Timed with precision helical gears, keyed to the rotor shafts
- Include double-row ball bearings at the gear end
- Rotors with integral shafts
- Reduced noise versions available with tri-lobe rotors
- Bi-directional rotation
Applications
Applications
- Chemical Processing
- Construction - Dry Bulk Transfer
- Food & Beverage - Pneumatic Conveying
- Vacuum Furnace
- Water & Wastewater
Dimensions + Weight
Dimensions + Weight
- Weight: 245 lb
- Dimensions: 25 x 20 x 22 in
Additional Information
Additional Information
Contact us to access more information about this product via PDF downloads.

MD-Kinney
- a leader in the design and manufacture of high performance, reliable positive displacement blowers, mechanical vacuum pumps, vacuum boosters and engineered systems ready to install and run.
Applications
Chemical Processing
Positive displacement blowers are required to create a predictable amount of flow handle chemical gases with various properties such as flammable, corrosive, hazardous, high pressure and high temperature gases.
PD Plus blowers have a long history of being the ideal blower for specialty gases. MD-Kinney is known for its wide range of special materials, coatings, seals and our vast experience providing blowers and gas pressure boosters
Construction - Dry Bulk Transfer
The use of a blower in the Dry Bulk Transfer application is to transfer dry bulk product from the truck to the customer point. The truck blower is required to be rugged due to its exposure to the elements while mounted on the truck.
MD-Kinney Truck blowers are ideally suited for offloading dry bulk trailers. The blowers are typically mounted on tractor frame rails and are driven by transmission mounted Power Take-Offs. Dry bulk trailers are used to transport materials such as cement, flash, sand limestone and other materials used in the construction industry as well as food grade products such as flour, sugar, plastic pellets etc. MD-Kinney offers the T850 & T1050 lobe blowers and the T650 screw blower.
Our lobe blowers provide pressures of up to 20 psi & 17″ HG continuous vacuum capability, include oil reservoirs on both ends and have no ‘external breathers’ which prevents water from leaking into the oil reservoirs. The blowers are supplied with large bearings and drive shafts, and include our patented Shur-Melt Thermal Relief Plugs that provide protection against heat and over pressurization giving users peace of mind and years of rugged performance.
The 25 psi capable T650 screw blower utilizes PTFE coated non-contacting screw rotors that prevent degradation of the blower housing and eliminates the need for constant maintenance, common in vane blowers that require on-going vane replacement. Its unique design, an industry first, allows the blower, complete with inlet filter and discharge silencer, to be mounted on the inside of the tractor frame rail saving valuable space.
Food & Beverage - Pneumatic Conveying
The use of positive displacement blowers in Pneumatic Conveying provides efficient transfer of dry bulk material from point to point at varying pressures and vacuum levels.
The MD Pneumatics™ Blower and MD-Kinney Blower Packages provide consistent air flow regardless of pressure and demand, without contaminating the material in the process.
Vacuum Furnace
MD-Kinney’s Kinney rotary piston vacuum pumps are proven to be extremely reliable due to their “no metal-to-metal” contact in the pump chamber, large oil capacity, large oil lines, low temperature operation and vibration free characteristics. Kinney pumps are considered the standard for many vacuum furnace applications and are known for many years of product life with minimal maintenance. The “total cost” of aKinney rotary piston pump in a vacuum furnace application is normally the lowest of any type of vacuum pump available.
The “Vacuum Furnace” market is one with many varying applications. The common theme is large chambers used on 2-3 shifts per day cycles. The chambers have various metals inside heated to temperatures in the 2000 degree C range. This produces high amounts of product off-gassing. The vacuum pump needs to a very durable one to handle the high amounts of vapor and off-gassing, which is ideal for Kinney Rotary Piston Vacuum Pumps.
Water & Wastewater
MD-Kinney’s M-D Pneumatics™ rotary positive blowers and blower packages are ideal for a number of applications in the wastewater market. The most common use is aeration where the blower is used to supply oxygen to the aeration tank or pond. Blowers are also used for basic sewage and sludge movement as well as the transfer of digester gases.
